- power supply: 12V DC
- outputs: 12V DC / 400mA per channel (total : max 4A)
- dimensions PCB: 140 x 100 x 27mm (5.5" x 3.9" x 1.1")
- 10 x 12V/400mA outputs to control cold-cathode fluorescent lamps (using FLPS adapter), light bulbs, LEDs and "solid state" relays, ...
- for use with advertisement lighting, party lights, eye-catchers, in the disco...
- ten pre-programmed light patterns selectable with a push button
- the number of used channels is adjustable
- the last used lighting effect is saved in non-volatile memory
- adjustable speed
- LED indication for every output
- 12V operation possible for use in cars
- options:
- adapter: PSS1255 (12V output 5.5A)
- power supply for cold-cathode fluorescent lamps: FLPS (300mm) or FLPS1 (100mm)
- cold-cathode fluorescent lamps: FL(xx) - (100 or 300mm)
- solid-state relays: VR25SS1A or VR3SS1A: SOLID STATE POWER RELAY 3A / 240V 1 x on to drive mains voltage lamps
