Features

• Single power source: 3.3V, onboard regulator
• Standard 0.1 inch (2.54mm) pin pitch header connector
• High sensitivity suitable for illumination applications
• Low voltage suitable for embedded applications
• Standard SCCB interface compatible with I2C interface
• 50/60Hz automatic detection
• Photosensitive array: 640x480 pixel
• IO Voltage: 2.5V to 3.0V (internal LDO for nuclear power 1.8V)
• Power operation: 60mW/15fpsVGAYUV
• Sleep: 20μA
• Temperature Operating: -30 ℃ to 70 ℃
• Stable: 0 ℃ to 50 ℃
• Output Formats (8): YUV/YCbCr4: 2:2 RGB565/555/444 GRB4: 2:2 Raw RGB Data
• Optical size: 1/6 "
• FOV: 25 °
• Maximum Zhen rate: 30fps VGA
• Sensitivity: 1.3V / (Lux-sec)
• SNR: 46 dB
• Dynamic range: 52 dB
• View Mode: Progressive
• Electronic Exposure: 1 line to 510 line
• Pixel Size: 3.6μm x 3.6μm
• Dark current: 12 mV / s at 60 ℃
