ideal for use with flexible LED light lights strips

• 256 intensity levels/ch.
• voltage output: same as input voltage
• current limit possible (on-board resistor needed)
• LED PWM freq: 82Hz
• power supply: 10-15VDC/9A max. OR 24VDC regulated /3A max. (e.g. PSIN06024)*
• dimensions: + 80x70x23mm / 3.15 x 2.75 x 0.9"

• suited for both incandescent bulbs and LEDs
• up-down level adjust for each output
• hard transition effects: runnning light, Strobo, Colour loops, etc...
• smooth fade effects: colour change, flame effect, random colours, slow off etc...
• wide-range effect speed adjust
• Hi power MOSFET outputs
• memory for last selected effect & speed
• easy up/down effect select
• suited for common anode RGB strips
• also available as completely mounted module VM146

• * Remark

  Only connect 1 RGB LED strip of max. 3x1A/24V
